SPME fibers
Sorptive extraction is a convenient approach for complex samples and for monitoring persistent organic pollutants in foods, beverages and other products derived from natural sources. In SPME, (solid-phase microextraction) fibers are coated with absorptive phase(s), to extract volatiles in either headspace or immersive modes.
- Compared with static headspace, SPME can offer improved selectivity and concentration capability
- A variety of sampling phases are available to extend the applicability of SPME over a range of target analytes
- SPME can be extended to SPME–trap with the Centri sample extraction and enrichment platform
Product List
Showing 52/52 results
Smart SPME fiber- PDMS
100 micrometer - 10 mm length- red- pk 1
Product Code
S2-FIB-P-100/10-P1
Smart SPME fiber- PDMS
100 micrometer - 10 mm length- red- pk 3
Product Code
S2-FIB-P-100/10-P3
Smart SPME fiber- PDMS
100 micrometer - 10 mm length- red- pk 5
Product Code
S2-FIB-P-100/10-P5
Smart SPME fiber- PDMS
30 micrometer - 10 mm length- gold- pk 1
Product Code
S2-FIB-P-30/10-P1
Smart SPME fiber- PDMS
30 micrometer - 10 mm length- gold- pk 3
Product Code
S2-FIB-P-30/10-P3
Smart SPME fiber- PDMS
30 micrometer - 10 mm length- gold- pk 5
Product Code
S2-FIB-P-30/10-P5
Smart SPME fiber- PDMS
7 micrometer - 10 mm length- green- pk 1
Product Code
S2-FIB-P-7/10-P1
Smart SPME fiber- PDMS
7 micrometer - 10 mm length- green- pk 3
Product Code
S2-FIB-P-7/10-P3
Smart SPME fiber- PDMS
7 micrometer - 10 mm length- green- pk 5
Product Code
S2-FIB-P-7/10-P5
Smart SPME arrow- PDMS
1.10 mm OD- 100 micrometer - 20 mm length- red- pk 1
Product Code
S2-ARR11-P-100/20-P1
Smart SPME arrow- PDMS
1.10 mm OD- 100 micrometer - 20 mm length- red- pk 3
Product Code
S2-ARR11-P-100/20-P3
Smart SPME arrow- PDMS
1.10 mm OD- 100 micrometer - 20 mm length- red- pk 5
Product Code
S2-ARR11-P-100/20-P5
Smart SPME arrow- PDMS
1.50 mm OD- 100 micrometer - 20 mm length- red- pk 1
Product Code
S2-ARR15-P-100/20-P1
Smart SPME arrow- PDMS
1.50 mm OD- 100 micrometer - 20 mm length- red- pk 3
Product Code
S2-ARR15-P-100/20-P3
Smart SPME arrow- PDMS
1.50 mm OD- 100 micrometer - 20 mm length- red- pk 5
Product Code
S2-ARR15-P-100/20-P5
Smart SPME fiber- Acrylate
85 micrometer - 10 mm length- grey- pk 1
Product Code
S2-FIB-A-85/10-P1
Smart SPME fiber- Acrylate
85 micrometer - 10 mm length- grey- pk 3
Product Code
S2-FIB-A-85/10-P3
Smart SPME fiber- Acrylate
85 micrometer - 10 mm length- grey- pk 5
Product Code
S2-FIB-A-85/10-P5
Smart SPME arrow- Acrylate
1.10 mm OD- 100 micrometer - 20 mm length- grey- pk 1
Product Code
S2-ARR11-A-100/20-P1
Smart SPME arrow- Acrylate
1.10 mm OD- 100 micrometer - 20 mm length- grey- pk 3
Product Code
S2-ARR11-A-100/20-P3
Smart SPME arrow- Acrylate
1.10 mm OD- 100 micrometer - 20 mm length- grey- pk 5
Product Code
S2-ARR11-A-100/20-P5
Smart SPME fiber- DVB/PDMS
65micrometer - 10 mm length- violet- pk 1
Product Code
S2-FIB-DVB-65/10-P1
Smart SPME fiber- DVB/PDMS
65micrometer - 10 mm length- violet- pk 3
Product Code
S2-FIB-DVB-65/10-P3
Smart SPME fiber- DVB/PDMS
65micrometer - 10 mm length- violet- pk 5
Product Code
S2-FIB-DVB-65/10-P5
Smart SPME arrow- DVB/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- violett- pk 1
Product Code
S2-ARR11-DVB-120/20-P1
Smart SPME arrow- DVB/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- violett- pk 3
Product Code
S2-ARR11-DVB-120/20-P3
Smart SPME arrow- DVB/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- violett- pk 5
Product Code
S2-ARR11-DVB-120/20-P5
Smart SPME arrow- DVB/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- violett- pk 1
Product Code
S2-ARR15-DVB-120/20-P1
Smart SPME arrow- DVB/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- violett- pk 3
Product Code
S2-ARR15-DVB-120/20-P3
Smart SPME arrow- DVB/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- violett- pk 5
Product Code
S2-ARR15-DVB-120/20-P5
Smart SPME fiber- Carbon Wide Range (CWR)/PDMS
95 micrometer - 10 mm length- dark blue- pk 1
Product Code
S2-FIB-C-WR-95/10-P1
Smart SPME fiber- Carbon Wide Range (CWR)/PDMS
95 micrometer - 10 mm length- dark blue- pk 3
Product Code
S2-FIB-C-WR-95/10-P3
Smart SPME fiber- Carbon Wide Range (CWR)/PDMS
95 micrometer - 10 mm length- dark blue- pk 5
Product Code
S2-FIB-C-WR-95/10-P5
Smart SPME arrow- Carbon Wide Range (CWR)/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- light blue- pk 1
Product Code
S2-ARR11-C-WR-120/20-P1
Smart SPME arrow- Carbon Wide Range (CWR)/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- light blue- pk 3
Product Code
S2-ARR11-C-WR-120/20-P3
Smart SPME arrow- Carbon Wide Range (CWR)/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- light blue- pk 5
Product Code
S2-ARR11-C-WR-120/20-P5
Smart SPME arrow- Carbon Wide Range (CWR)/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- light blue- pk 1
Product Code
S2-SARR15-C-WR-120/20-P1
Smart SPME arrow- Carbon Wide Range (CWR)/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- light blue- pk 3
Product Code
S2-SARR15-C-WR-120/20-P3
Smart SPME arrow- Carbon Wide Range (CWR)/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- light blue- pk 5
Product Code
S2-SARR15-C-WR-120/20-P5
Smart SPME fiber- DVB/Carbon Wide Range (CWR)/PDMS
50/30 micrometer - 10 mm length- dark grey- pk 1
Product Code
S2-FIB-DVB/C-WR-80/10-P1
Smart SPME fiber- DVB/Carbon Wide Range (CWR)/PDMS
50/30 micrometer - 10 mm length- dark grey- pk 3
Product Code
S2-FIB-DVB/C-WR-80/10-P3
Smart SPME fiber- DVB/Carbon Wide Range (CWR)/PDMS
50/30 micrometer - 10 mm length- dark grey- pk 5
Product Code
S2-FIB-DVB/C-WR-80/10-P5
Smart SPME arrow- DVB/Carbon Wide Range (CWR)/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- dark grey- pk 1
Product Code
S2-ARR11-DVB/CWR120/20-P1
Smart SPME arrow- DVB/Carbon Wide Range (CWR)/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- dark grey- pk 3
Product Code
S2-ARR11-DVB/CWR120/20-P3
Smart SPME arrow- DVB/Carbon Wide Range (CWR)/PDMS
1.10 mm OD- 120 micrometer - 20 mm length- dark grey- pk 5
Product Code
S2-ARR11-DVB/CWR120/20-P5
Smart SPME arrow- DVB/Carbon Wide Range (CWR)/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- dark grey- pk 1
Product Code
S2-ARR15-DVB/CWR120/20-P1
Smart SPME arrow- DVB/Carbon Wide Range (CWR)/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- dark grey- pk 3
Product Code
S2-ARR15-DVB/CWR120/20-P3
Smart SPME arrow- DVB/Carbon Wide Range (CWR)/PDMS
1.50 mm OD- 120 micrometer - 20 mm length- dark grey- pk 5
Product Code
S2-ARR15-DVB/CWR120/20-P5
Smart SPME fiber- collection of 5
10 mm length: 7- 30 and 100 micrometer (PDMS)- 85 micrometer (Acrylate)- 95 micrometer (Carbon Wide Range)
Product Code
S2-FIB-SEL5-S1
Smart SPME fiber- collection of 5
10 mm length: 100 micrometer (PDMS)- 65 micrometer (DVB)- 95 micrometer (Carbon Wide Range)- 85 micrometer (Acrylate)- 80 micrometer (DVB/Carbon Wide Range)
Product Code
S2-FIB-SEL5-S2
Smart SPME arrows- collection of 5
1.10 mm OD and 20 mm length: 100 micrometer (PDMS)- 120 micrometer (Carbon Wide Range/PDMS)- 120 micrometer (DVB/PDMS)- 100 micrometer (PDMS)- 120 micrometer (DVB/Carbon Wide Range/PDMS)
Product Code
S2-ARR1115-SEL5-S2
Manual injector kit- SPME (fiber and arrow)
For manual injection of SPME fiber and SPME arrow
Product Code
C-MIK-SPME
Overview
SPME extraction is dependent on the equilibrium between the sample matrix (either liquid, solid or headspace) and the absorptive phase. Analytes that become absorbed into the SPME phase are subsequently desorbed using a heated injector before transfer to the GC column, a process that can be fully automated using Centri. The simple solvent-free nature of SPME has led to its increased popularity across a range of application areas, particularly in food and beverage analysis, clinical studies and environmental analysis.
SPME–trap is an innovative injection mode that provides enhanced sample information by improving peak shape and so enhancing detection limits, and also by allowing multiple sample enrichments onto the focusing trap prior to injection.
A manual injector kit is available for manual sample introduction to the GC.
Part numbers:
S2-ARR1115-SEL5-S2 - S2-ARR11-A-100/20-P1 - S2-ARR11-A-100/20-P3 - S2-ARR11-A-100/20-P5 - S2-ARR11-C-WR-120/20-P1 - S2-ARR11-C-WR-120/20-P3 - S2-ARR11-C-WR-120/20-P5 - S2-ARR11-DVB/CWR120/20-P1 - S2-ARR11-DVB/CWR120/20-P3 - S2-ARR11-DVB/CWR120/20-P5 - S2-ARR11-DVB-120/20-P1 - S2-ARR11-DVB-120/20-P3 - S2-ARR11-DVB-120/20-P5 - S2-ARR11-P-100/20-P1 - S2-ARR11-P-100/20-P3 - S2-ARR11-P-100/20-P5 - S2-ARR15-DVB/CWR120/20-P1 - S2-ARR15-DVB/CWR120/20-P3 - S2-ARR15-DVB/CWR120/20-P5 - S2-ARR15-DVB-120/20-P1 - S2-ARR15-DVB-120/20-P3 - S2-ARR15-DVB-120/20-P5 - S2-ARR15-P-100/20-P1 - S2-ARR15-P-100/20-P3 - S2-ARR15-P-100/20-P5 - S2-ARR15-P-250/20-P1 - S2-ARR15-P-250/20-P3 - S2-ARR15-P-250/20-P5 - S2-FIB-A-85/10-P1 - S2-FIB-A-85/10-P3 - S2-FIB-A-85/10-P5 - S2-FIB-C-WR-95/10-P1 - S2-FIB-C-WR-95/10-P3 - S2-FIB-C-WR-95/10-P5 - S2-FIB-DVB/C-WR-80/10-P1 - S2-FIB-DVB/C-WR-80/10-P3 - S2-FIB-DVB/C-WR-80/10-P5 - S2-FIB-DVB-65/10-P1 - S2-FIB-DVB-65/10-P3 - S2-FIB-DVB-65/10-P5 - S2-FIB-P-100/10-P1 - S2-FIB-P-100/10-P3 - S2-FIB-P-100/10-P5 - S2-FIB-P-30/10-P1 - S2-FIB-P-30/10-P3 - S2-FIB-P-30/10-P5 - S2-FIB-P-7/10-P1 - S2-FIB-P-7/10-P3 - S2-FIB-P-7/10-P5 - S2-FIB-SEL5-S1 - S2-FIB-SEL5-S2 - S2-SARR15-C-WR-120/20-P1 - S2-SARR15-C-WR-120/20-P3 - S2-SARR15-C-WR-120/20-P5
