Thermal desorption instrumentation

World-leading thermal desorption instruments for GC | Tubes, canisters and online

Details

Sorbent tube analysis

There are two types of sampling with sorbent tubes – pumped and passive. Using pumped sampling, air is pulled through a sorbent tube using a pump. Single-bed or multi-bed tubes can be used. A constant flow of gas into the vessel aids release of analytes onto a sorbent tube. Typical analytes monitored by this method are in the range C3 to C44. Sampling is quick (minutes to hours) and a wide range can be monitored in one run. The technique is ideal for all types of ambient air monitoring. With passive sampling, analytes migrate across an air gap onto a bed of sorbent. Here, only single-bed tubes can be used. Typical analytes monitored are also in the range C3 to C44. Passive sampling is easy to deploy but is relatively slow. The technique is commonly used for factory fenceline monitoring and personal monitoring.

Unity Xr. RF

UNITY-xr

Single-tube thermal desorption unit with unmatched upgradability

Find out more
TD100 Xr (Door Closed) From Right

TD100-xr

Multi-tube thermal desorber for high-throughput automated analysis

Find out more
Unity Xr & Ultra FF

UNITY–ULTRA-xr

Multi-tube thermal desorber with advanced upgrade options

Find out more
UNITY-ULTRA-xr Pro

UNITY–ULTRA-xr Pro

Multi-tube thermal desorber with advanced re-collection options

Find out more
UNITY-ULTRA-xr (DAAMS)

DAAMS instruments

Automated thermal desorption for 4½" sorbent tube analysis

Find out more
Centri From Right Above

Centri

The ultimate automated multi-mode extraction and enrichment platform for GC–MS

Find out more

On-line sampling & analysis

During on-line sampling, air is pulled directly into a sorbent-packed focusing trap. Typical analytes monitored by this method are freons and C2 hydrocarbons up to C14. On-line sampling is ideal for ultra-volatiles and is commonly used for continuous monitoring for source apportionment, rapid detection of hazardous compounds and atmospheric research.

UNITY Xr Air Server Xr From Left

UNITY–Air Server-xr

Cryogen-free automated thermal desorption system for unattended on-line air monitoring

Find out more
UNITY Xr CIA Advantage Xr From Left

UNITY–CIA Advantage-xr

Cryogen-free, automated canister and whole air preconcentration system

Find out more
TT24 7 From Left

TT24-7

Advanced thermal desorber for uninterrupted monitoring of trace chemical vapours

Find out more

Canister & bag sampling & analysis

With canister and bag sampling, air flows at a controlled rate into an evacuated canister or bag. The air sample is then transferred to a sorbent-packed focusing trap. Typical analytes monitored are freons and C2 hydrocarbons up to C10. Canister and bag sampling are ideal for ultra-volatiles and are commonly used for ambient air monitoring for volatile ‘air toxics’ and atmospheric research.

UNITY Xr CIA Advantage Xr From Left

UNITY–CIA Advantage-xr

Cryogen-free, automated canister and whole air preconcentration system

Find out more

Accessories

Accessories to enhance your thermal desorption instruments and sampling.

Kori Xr From Left

Kori-xr

Cryogen-free water management module for online and canister samples

Find out more
MCTE120 And MCTE250 With Tubes

Micro-Chamber/Thermal Extractor

Fast and flexible sampling of chemical and odours released from materials and food

Find out more
MTS 32

MTS-32

Multi-tube sequential sampler

Find out more
TC 20 Tubes In

TC-20 & TC-20 TAG

Conditioning and dry-purging units for multiple sorbent tubes

Find out more

Overview of thermal desorption

Thermal desorption (TD) arose out of the need to improve upon conventional sample preparation techniques such as solvent extraction, solid-phase microextraction, purge-and-trap and static headspace. It gives greater sensitivity than these techniques and can be used for a wider range of compound classes ranging in volatility from C2 to n-C44 hydrocarbons. TD is also applicable to a wide range of sample types – solids (using dynamic headspace, headspace sorptive extraction or direct desorption), liquids (using immersive sorptive extraction) and gases (using pumped sampling, passive sampling, on-line sampling or canisters). It is safer and more environmentally friendly than solvent extraction, is easily automated, easy to validate and complies with key standard methods.

What is thermal desorption?

TD is a versatile preconcentration and injection technique for gas chromatography, which is often used to automate analysis of volatile and semi-volatile organic compounds in air, gas and materials. Modern sorbent technology and sophisticated TD instrumentation can be optimised to capture the widest range of analytes for both target and untargeted analysis whilst ensuring selective purging of interferences such as solvents and water from the analytical system. The adsorbent trapping and thermal desorption process can handle wide dynamic and analyte ranges, allowing for the detection of ultra-volatiles to semi-volatiles in concentrations ranging from part-per-trillion (ppt) to low-percent levels. TD also greatly improves sample throughput and is easily automated and validated, saving time and manpower.

The majority of TD applications use sorbent tubes and a two-stage desorption process to focus the analytes into a narrow, capillary GC-compatible band of gas, and so achieve the maximum concentration enhancement and sensitivity.

The process consists of three steps:

  • Sample collection: Up to several hundred litres of vapour is sampled off-line onto a sorbent tube.
  • Tube desorption: The sample is heated in a flow of carrier gas and the analytes swept onto an electrically-cooled focusing trap.
  • Trap desorption: At the end of tube desorption, the focusing trap heats rapidly in a reverse flow of carrier gas transferring or injecting the analytes into the GC column as a narrow band. Analytes are transferred to the GC in just a few hundred micro-litres of carrier gas providing pre-concentration factors of several orders of magnitude.

Alternatively, volumes of whole air or gas, collected in canisters, bags, or from on-line air/gas streams can be introduced directly to the electrically cooled focusing trap for concentration and desorption/transfer into the GC column.

Sample materials can also be weighed directly into empty TD sample tubes or liners for selective extraction/desorption of retained volatiles in a dynamic headspace process.
